Electric 3 way Clamp Ball Valve

Electric 3 way Clamp Ball Valve


Product name:Electric 3 way Clamp Ball Valve
Item:DHBV-E
Details:
Product name:Electric 3 way Clamp Ball Valve
Model:DHBV-E

Nominal diameter:DN15~DN300
Body material: WCB, 304, 316
Connection: flange, screw thread
Pressure range: PN1.6~4.0MPa
Structure: 3way T/L type float ball core
Seat sealing: PTFE:-30~180℃, PPL:-30~250℃
Hard seal: -30~450℃
Hard alloy: surface spray welding, tungsten nitride
Core material: 304, 316, 316L
Hard seal core surface spray welding, tungsten nitride.
Stem material:304
Applicable medium: water, liquid, gas, oil, powder, steam, acid and alkali corrosive medium
