Electric High Pressure Ball Valve

Electric High Pressure Ball Valve


Product name:Electric High Pressure Ball Valve
Item:DHBV-E
Details:

Product  name: Electric High Pressure Ball Valve
Model: DHBV-E

Nominal diameter: DN10~DN50
Body material: WCB, 304, 316, 316L
Connection: Flange, thread
Pressure range: PN10.0~50.0MPa
Structure: Straight 2 way, 3 way T type, 3 way L type
Seat sealing: PTFE
Core material: 304, 316, 316L
Stem material: 304
Applicable medium: High pressure gas, liquid, oil, etc.
