Pneumatic Sanitary Ball Valve

Pneumatic Sanitary Ball Valve


Product name:Pneumatic Sanitary Ball Valve
Item:DHBV-P
Details:
 Standard technical parameters

Valve body

Nominal diameter:Φ20-Φ102

Body material: 304, 316, 316L

Connection: Clamp, welding type

Pressure class: PN1.6MPa

Structure: 2way fl oating ball core

3way L / T- type fl oating core

Valve components

Seat sealing: PTFE:-30~180 , PPL:-30~250

Core material: 304, 316, 316L

Stem material: 304

Applicable medium: Food, medicine, packaging machinery,

fi lling machinery and other health conditions using level.

Design standard: ISO, DIN, IDF, SMS, 3A
