Working medium:liquid,gas,light oil(viscosity≤20cst)

Ambient temperature:-20℃~+65℃

Fluid temperature:-10~80℃

Working pressure:6~100bar(See the details below)

Working type:pilot operated

Body material:SS304

Sealing material:PTFE

Connection type:thread connection(G thread,NPT thread),flange connection

Working voltage:ES coil:AC220V star 130VA,hold 6VA,AC110Vstar95VA,hold 9VA,DC24Vstar 44W hold 6W,IP65

Optional: Normal coil:AC220V24VA,DC24V/DC12V 20W,Other voltages can be customized,IP65

                LED light connector,Ex:encapsulated Ex-proof coil,Digital timer, Rc thread

This series is UL certified
