Model |
RSV-025-06 |
RSV-025-08 |
RSV-130-10 |
RSV-130-15 |
RSV-250-20 |
RSV-250-25 |
|
|
G Connection |
1/8" |
1/4" |
3/8" |
1/2" |
3/4" |
1" |
|
|
Orifice Size |
mm |
2.5 |
13 |
25 |
|||
|
Motion Pattern |
Direct Action |
Pilot Operated |
|||||
|
Cv Value |
|
0.23 |
6.2 |
23 |
|||
|
L |
mm |
30 |
72 |
102 |
|||
|
H |
mm |
76 |
103 |
120 |
|||
|
H1 |
mm |
66 |
88 |
95 |
|||
|
Medium |
-10 ÷80℃ |
||||||
|
Pressure |
bar |
0.3 ÷ 8 |
|||||
|
Power |
AC:220V~AC:230V/50-60HZ 4.5VA; DC24 6W; Range:±10%, |
||||||
[Note] In case use for special pressure,voltages and so on,please state with your order.
Technical Specification
Medium:Water,Air,Oil(below 20cst)
Temperature:-10~80℃
Mode of action:Direct acting/Pilot Operated
Pressure:Normally Closed(N/C) 8bar
Body material:Brass
Sealing material:NBR
Protection class:IP65
[Note]
Viton(V):suitable to hot water,acid,alkali,chemical salt,oil and hydrocarbon;the MAX.130℃.In case you choose Viton.please state ‘V’ in your order.
