2/2 Way DFD-CF Seriers Solenoid Valve
Technical Specifications
Medium:Water ,Air,Oil(below 20cst)
Temperature:-5~+80℃
Mode of action:Pilot operated
Pressure:Normally Closed(N/C)12bar
Normally Open(N/O)8bar
Body material:Cast iron
Sealing material:NBR
Protection class:IP65
|
Model |
Flange D |
Flange D1 |
Flange D2 |
|
DFD-40CF |
150 |
110 |
4-Φ18 |
|
DFD-50CF |
165 |
125 |
4-Φ18 |
|
DFD-65CF |
185 |
145 |
4-Φ18 |
|
DFD-80CF |
200 |
160 |
8-Φ18 |
|
DFD-100CF |
220 |
180 |
8-Φ18 |
|
DFD-125CF |
250 |
210 |
8-Φ18 |
|
DFD-150CF |
285 |
240 |
8-Φ22 |
|
DFD-200CF |
340 |
295 |
12-Φ22 |
PARAMETERS(N/T)
|
Model |
DFD-40CF |
DFD-50CF |
DFD-65CF |
DFD-80CF |
DFD-100CF |
DFD-125CF |
DFD-150CF |
DFD-200CF |
|||||||||
|
Flange connection |
mm |
11/2″ |
2″ |
21/2″ |
3″ |
4″ |
5″ |
6″ |
8″ |
||||||||
|
Orifice Size |
40 |
50 |
65 |
80 |
100 |
125 |
150 |
200 |
|||||||||
|
Motion Pattern |
Pilot Operated |
||||||||||||||||
|
Cv Value |
21 |
30 |
52.5 |
81.7 |
128.4 |
221.7 |
291.7 |
513.5 |
|||||||||
|
L |
Mm |
182 |
215 |
256 |
277 |
350 |
425 |
450 |
560 |
||||||||
|
H |
Mm |
196 |
200 |
280 |
287 |
330 |
437 |
460 |
547 |
||||||||
|
H1 |
Mm |
125 |
120 |
185 |
19 |
230 |
310 |
318 |
380 |
||||||||
|
Mediu temperature℃ |
-5~+80℃ |
||||||||||||||||
|
Pressure |
Bar |
N/C:0.3÷12(0.3÷16) N/O:0.3÷8 |
|||||||||||||||
|
Powder |
220V~230V AC/50~60Hz 25VA;110V~120AC/50~60Hz 26VA;DC 24V 12 W;DC 12V 14W;Range:±10% |
||||||||||||||||
Note In case use for special pressure,voltages and so on,please state with your order.
