VASAFA10 glass tube flowmeter

VASAFA10 glass tube flowmeter


Product name:VASAFA10 glass tube flowmeter
Item:USD 35~350 / Piece
Details:

                                         VASAFA10 glass tube flowmeter



 VA/FA/SA10 series flow meters are manufactured the same as the special technique
and equipment of KROHNE company in German.
In addition to the mm graduation scale and percentage scale on the glass cone, a replaceable
scale with flow units can on request be fitting to the housing.
VA10 have screw connection, FA10 have flange connection, SA10 have hose connedtion.



Technical parameter



1.Measuring range: Water (20 ) 4 15000L/h        Air (1.013×105Pa, 20 ) 0.12 300m3/h

2.Range scale: 10: 1

3.Accuracy: 1.0; 1.6

4.Tube: NG60 (no-oriented)

            FG60 (oriented)

5. Float : NG60 : A III

              FG60 : C III, D III, C III L, D III L, Z III

6. Fluid press: DN15,DN25: 1.0 MPa

                        DN40: 0.9 MPa

                        DN50:0.7 MPa

7.Fluid temperature: -20   +60 or 0   +120


Specification

DN

(mm)

Model

Measuring range

Basic

Corosive rsistant

Water (20

L/h

Air(101325Pa,20)

M3/h

15

VA/SA/FA10-15

VA/SA/FA10-15F

4-40

6.3-63

10-100

12-120

16-160

20-200

25-250

30-300

36-360

40-400

46-460

63-630

65-650

75-750

0.12-1.2

0.2-2

0.3-3

0.4-4

0.5-5

0.6-6

0.8-8

0.9-9

1.2-12

2-20

25

VA/SA/FA10-25

VA/SA/FA10-25F

40-400

50-500

63-630

80-800

100-1000

120-1200

160-1600

200-2000

250-2500

300-3000

1.6-16

2-20

2.5-25

3-30

4-40

5-50

6-60

40

VA/SA/FA10-40

VA/SA/FA10-40F

160-1600

200-2000

250-2500

300-3000

     400-4000

500-5000

5-50

6-60

8-80

9-90

12-120

50

VA/SA/FA10-50

VA/SA/FA10-50F

250-2500

300-3000

     400-4000

500-5000

630-6300

800-8000

1000-10000

1500-15000

10-100

12-120

16-160

20-200

30-300
