Angle Seat Valve DH2000 series

Angle Seat Valve DH2000 series


Product name:Angle Seat Valve DH2000 series
Item:
Details:

Angle Seat Valve  DH2000 series

Darhor's angle seat valve. Designed for unmatched life cycle

performance, is a perfect replacement for actuated ball valves.

Design character

High flow rate due to the angle seat configuration♦ .

♦ Anti-water hammer feature with the fluid entry below the seat.

♦ Stainless steel body and corrosion resistant actuator.

♦ The pneumatic actuator can be rotated through 360 degrees.

♦ Optical position indicator.

♦ Internal seals are self adjusting for long life,no need maintenance

♦ Easily convertible from N.C. to N.O. or double acting.

♦ Universal mounting - any mounting orientation is acceptable



Application

Steam Applications

Air Drying Equipment

Process Control Applications

Sterilizers and autoclaves

Laundry Equipment

Textile Dyeing & Drying

Bottling & Dispensing Equipment

Industrial project

Ink & Paint Dispensing

Chemical and Petrochemical Industries

Paper and Pulp Industries

Cooling system

Nuclear Energy



The Angle Seat Valve is a 2/2-way pneumatically actuated piston valve for liquids,

gases, steam and some aggressive fluids (vacuum services also.) The superior

design of the piston is unique to the market, enabling the plug to retract farther from

the flow path, ensuring the highest flow capacity. The dual packing design, and a

large diameter self aligning stem insures the highest cycle life. A full range of

accessory items are available including limit switches, solenoid valves, manual

override devices, stroke limiters.
