DHL21 small latching solenoid valve

DHL21 small latching solenoid valve


Product name:DHL21 small latching solenoid valve
Item:
Details:
DHL21 Series Direct acting, pilot operating diaphragm structure

Characteristic:  1.With latching coil at low power consumption
                          2.Applied to washroom, public W.C. etc.
                          3.Lifespan can be at 1 million cycles.
Temperature:     NBR Seal: 14F to 176F, -10 to 80
EPDM Seal:        14F to 250F, -10 to 120
VITON Seal:      14F to 300F, -10 to 150
Pressure:          DHL21: 0 ~ 10 bar
Port Size:          1/8", 1/4"
Port Thread:      G, BSPT, NPT, Flange
Orifice (mm):     15, 20, 25, 32, 40, 50
Voltage:             DC - 6V, 12V, 24V
Coils:                 L11B, 2W (DC), IP65 100%ED
Material:            Body - Brass or stainless steela
                         Seal -NBR, EPDM or VITON
                         Armature Tube - Stainless Steel 304
                         Plunger - Stainless Steel 430F
                         Stop -SS430F
                         Springs - SS 304
                         Shading Rings - Stainless Steel 304
DHL21 Series, Direct acting with Coil L11B
