DHPG31-S steam solenoid valve

DHPG31-S steam solenoid valve


Product name:DHPG31-S steam solenoid valve
Item:USD55~USD190
Details:

DHPG31 Series Piston Pilot Operated, High Temperature 1/2-2”2WAY N.C

Characteristic:  1. Pilot operated piston construction with low power consumption
                        2. Seal serves longtime at steam ambient;
                                        3. Used for long-time working in pipeline system.

Medium:           Steam and Hot Water, Oil, etc.

Temperature:   PET Seal: -60to 250
                                         PEEK: -100 to 300
                                         PTFE: -60 to 250

Pressure:         DHPG31: 0.5 ~ 16 bar N.C

Port Size:         1/2", 3/4", 1", 1 1/4", 1 1/2", 2"

Port Thread:    G, BSP, NPT

Orifice (mm):   12, 15, 20, 25, 32, 40, 50

Voltage:           DC- 12V, 24V
                                        AC - 24V, 120V, 240V/60Hz110V, 220V/50Hz
Tolerance:       +/- 10%

Coils:               Y21H, 28VA (AC), 22W (DC), Ip65, 100%ED

Material:            Body- Stainless steel

Seal- PET

Armature Tube- Stainless Steel 304

Plunger- Stainless Steel 430F

Stop- SS430F

Springs- SS 304

Shading Rings - Stainless Steel 304

DHPG31 Normally Closed, with Coil Y21H

Port Size

Orifice

Cv

Min Pressure(bar)

Max Pressure(bar)

Valve Body

Coil

AC(22VA)

DC(17W)

3/8"

12

4.5

0. 5

16

16

DHPG3112 X X X

Y21H

1/2"

15

4.5

0. 5

16

16

DHPG3115 X X X

Y21H

3/4"

20

9.3

0. 5

16

16

DHPG3120 X X X

Y21H

1"

25

12

0. 5

16

16

DHPG3125 X X X

Y21H

1 1/4"

32

24

0. 5

16

16

DHPG3132 X X X

Y21H

1 1/2"

40

29

0. 5

16

16

DHPG3140 X X X

Y21H

2"

50

48

0. 5

16

16

DHPG3150 X X X

Y21H

F1"

25

12

0. 5

16

16

DHPG3125 X X X

Y21H

F1 1/4"

32

24

0. 5

16

16

DHPG3132 X X X

Y21H

F1 1/2"

40

29

0. 5

16

16

DHPG3140 X X X

Y21H

F2"

50

48

0. 5

16

16

DHPG3150 X X X

Y21H
